Our Engineered Metal Concrete Foundation Support Brackets come in multiple sizes to suit all precast step and deck installation situations. Due to their lightweight fabrication, our brackets are multi-functional and perfectly suited for applications on the front, side or rear of a home. These Foundation Concrete Support bracket sizes range from 3′ to 8′. We also carry this bracket in 3.5′ (42″).
These Foundation Support Brackets Bolt to the foundation using a two 5/8″ x 5″ Wedge Anchors and are designed to support sidewalks, pads, garages, cantilevers, decks, pillars and other features that may need support.
Each bracket is manufactured in 2″ x 2″ x 3/16″ Angle Iron. 2 holes in two 3/16″ x 2.5″ flat Iron pieces with a 90° corner are mounted to the tops of these brackets for a total of 4 holes for mounting on corner brackets. That makes these perfect for mounting on the corners of foundations so the bracket sticks out at a 45° angle at the corner. Two Wedge anchors are still used on these brackets: 1 on the short hole and 1 on the far hole.
These foundation support brackets are manufactured here in Calgary in our WCB certified welding shop as per our engineering specifications and then they are protected with a rust resistant primer.
| Length In ( ft ) | Height In | Supporting Weight lbs |
| 36″ (3′) | 15″ | 4100 |
| 42″ (3.5′) | 18″ | 3600 |
| 48″ (4′) | 20″ | 3000 |
| 60″ (5′) | 28″ | 2300 |
| 72″ (6′) | 30″ | 1600 |
| 84″ (7′) | 30″ | 1100 |
| 96″ (8′) | 30″ | 750 |
5/8″ Drill bit – sold separately
5/8″ x 5″ Wedge anchor – sold separately
5/8″ x 6″ wedge anchor – sold separately
