Saft Ls17500 A-Size Primary Battery – 3.6V Lithium Thionyl Chloride, 3600Mah Industrial Cell

Description

Saft A-size 3.6V 3600mAh LS17500 Battery – Long-lasting, High Performance Power Solution

Unlock exceptional power and reliability with the Saft LS 17500 Primary Li-SOCl2 battery. Designed for high-performance applications, this 3.6V battery delivers a remarkable 3600mAh capacity, offering the perfect solution for long-term, low-discharge needs. Whether you’re using it for utility metering, IoT devices, security systems, or professional electronics, this battery is engineered to perform in the toughest environments.

Key Features:

• Capacity: 3600mAh
• Voltage: 3.6V
• Battery Type: Lithium Thionyl Chloride (Li-SOCl2)
• Chemistry: Lithium Thionyl Chloride
• Dimensions: Length: 50.9mm (2.00″) x Diameter: 17.13mm (0.67″)
• Low Discharge Rate: Super low self-discharge ensures minimal energy loss when not in use.
• Shelf Life: Up to 10 years, offering extended performance and reduced replacement frequency.
• Temperature Range: -60°C to +85°C, ensuring optimal performance in a wide range of temperatures.
• Container: Stainless steel container and end caps, providing minimal magnetic signature.
• Sealing: Hermetic glass-to-metal sealing for reliable long-term use.
• Electrolyte: Non-flammable for enhanced safety.
• Non-rechargeable: Designed for high-current applications, once used, the battery cannot be recharged.

Performance and Longevity:

The Saft LS 17500 offers superior energy capacity with 1139 Wh/l and 592 Wh/kg, delivering a consistent voltage throughout its long lifespan. With an impressive range of up to 20 years of operation, you can trust this battery to power your critical devices for years to come. Its low self-discharge rate ensures that even after one year of storage at 20°C, less than 1% of the energy is lost, making it an ideal choice for long-term applications where reliability is key.

Applications:

This high-performance cell is perfect for a variety of devices and systems, including:

• Utility metering systems
• IoT devices
• Medical devices
• Alarm and security systems
• Tracking systems
• Professional electronics

The LS 17500 also boasts compliance with RoHS and REACH standards, ensuring it meets all necessary environmental, safety, and quality guidelines.

Specifications:

• Cell Size Reference: A
• Part Number: LS17500BA
• Nominal Capacity: 3600mAh
• Nominal Voltage: 3.6V at 0.2mA (20°C)
• Storage Temperature: Max 30°C
• Diameter: 17.16mm
• Height: 50.77mm
• Weight: 23g
• Li Metal Content: Approx. 0.9g
• EAN / GTIN: 4250889624989
• Termination Suffix: BA (Bare Cell)
• Open Circuit Voltage: 3.67V at 20°C
• Compliancy: IEC 60086-4, IEC 60079-11
• Pulse Capacity: Up to 250mA
• Maximum Continuous Current: 100mA
• Nominal Energy: 12.96Wh

Safety Notice:

• Warning: This battery poses a fire, explosion, and burn hazard. Do not solder directly to the cell.
• Storage: Ensure the storage area is clean, cool (preferably not exceeding 30°C), dry, and ventilated to preserve the battery’s long-term performance.

Why Choose Saft LS 17500?

The Saft LS 17500 battery is an excellent choice for professional applications that demand long-lasting power, exceptional reliability, and high performance. From the low self-discharge rate to the broad temperature range, this battery is engineered for those who require consistent and safe energy for critical systems.
